2D IMAGER HF680
- User Friendly LED Lighting Design
- Great Decoding Performance
- Support for Decoding in Extreme Conditions
- Lengthy Useful Life
The Honeywell HF680 features Hybrid Imaging Technology, making it compatible with various LCD and OLED smart-phone screens and paper-based product barcodes. Frequent switching of scanning modes by the user is not required, significantly boosting the decoding range and improving efficiency.
THe Honeywell HF680 can scan barcodes on mainstream LCD screens (with brightness level ranges of 10% to 100%) and OLED screens. It can also scan barcodes on paper with a print contrast of at least 20%, as well as barcodes that are highly dense, smudged, or contain complete information despite damage. This product applies to various workplaces, such as manufacturing facilities, medical treatment and healthcare facilities, and retail POSs.
Physical Dimensions (LxWxH):85mmx88mmx139mm Weight: 278 +/-10g
Electrical
Input voltage: 5 VDC ±0.5V Working: 2.0 W (400 mA @ 5V) Standby: 0.85 W (170 mA @ 5V) Host interface: SB, RS-232
Environmental
Operating temperature: -10°C to 40°C (14°F to 104°F) Storage temperature: -40°C to 60°C (-40°F to 140°F) Humidity: 0% to 95%RH, no condensation
Drop: Designed to withstand 1 m drops
Illuminance: 0-100,000 Lux
Scanning Performance
DPI:1280x800pixel
Motion tolerance: Up to 2.5 m/s for 13 mil UPC at optimal focus Scan angle: Horizontal: 47°; Vertical: 30°
Print Contrast: 20% minimum reflectance difference
Pitch, Skew: +/-60°, +/-70°
Decode Capability: Reads standard 1D, PDF, 2D Symbologie Note: Decode capabilities dependent on kit configuration. Warranty: 3-year factory warranty
